Nova Shell S85 – Maximum Protection PPF

Nova Shell S85 – Ultra Premium Paint Protection Film (8.5 MIL)
━━━━━━━━━━━━━━━━━━━━━━━
Key Features
━━━━━━━━━━━━━━━━━━━━━━━
TPU by Wanhua Chemical
– World-class TPU with superior strength, elasticity & long-term durability
Ashland Glue (USA)
– Strong & stable adhesion
– Clean, residue-free and paint-safe removal
Outstanding Peel Strength
• 18.7 N/in (≈ 1900 gf/in)
✓ Firm grip during installation
✓ No edge lifting
✓ Safe removal without OEM paint damage
Exceptional Stretchability
✓ Elongation at Break (Finished Product): 325%
✓ Repair Layer Elongation: 128%
✓ Smooth stretching with no cracking or whitening
High Gloss Finish
– 60° Gloss Value: 93.2 GU
– Deep shine with excellent optical clarity
Advanced Self-Healing Technology
– Light scratches heal automatically
– Faster recovery with hot water or warm air
– Noticeable repair within seconds
UV Protection
– UV Blocking Rate: 92.8%
– Protects paint from fading & oxidation
Heavy-Duty Surface Protection
– Superior resistance against stone chips, swirls & scratches
– Pencil Hardness: 3H
Chemical & Oil Resistance
– Resistant to oil-based ink, chemicals & daily contaminants
Installer-Friendly Film
– Stable positioning
– Bubble-free, smooth and professional finish
━━━━━━━━━━━━━━━━━━━━━━━
Technical Performance
━━━━━━━━━━━━━━━━━━━━━━━
Total Thickness: 344 μm (≈ 8.5 MIL)
Use Layer Thickness: 217 μm
Base Film Thickness: 181 μm
Protective / Installation Layer: 51 μm
Repair (Self-Healing) Layer: 30 μm
Release Liner Thickness: 76 μm
Peel Strength: 18.7 N/in (≈1900 gf/in)
Tensile Strength: 20 MPa
Elastic Modulus: 1524
Haze: 0.35%
Gloss (60°): 93.2 GU
UV Rejection: 92.8%
Self-Healing: Yes
Test Standards: ASTM / GB-T
